Name
RUD VLBG-PLUS-2t-M16 Load Ring with ICE-bolt
SKU
VLBG-PLUS-2t-M16
Brand
Condition
New
| Attribute | Value (Metric) | Value (Imperial) |
|---|---|---|
| Weight | 0.55 kg | 1.21 lbs |
| Nominal WLL | 2000 kg | 4400 lbs |
| T | 85 mm | 3-11/32" |
| A | 34.5 mm | 1-5/16" |
| B | 56 mm | 2-3/16" |
| C | 38 mm | 1-1/2" |
| D | 30 mm | 1-3/16" |
| E | 39 mm | 1-9/16" |
| F | 13.5 mm | 17/32" |
| G | 36 mm | 1-27/64" |
| H | 22 mm | 7/8" |
| I | 86 mm | 3-3/8" |
| K | 47 mm | 1-7/8" |
| L | 58 mm | 2-9/32" |
| M | M16 mm | M16 |
| N | 38 mm | 1-1/2" |
- Optimum WLL with captive but exchangable ICE-Bolt
- Bracket adjustable in force direction
- Comprehensive range of threads
- DNV certification from size M30.
