Name
RUD VRS-7t-M36 Vario Eye Bolt Starpoint
SKU
VRS-7t-M36
Brand
Condition
New
| Attribute | Value (Metric) | Value (Imperial) |
|---|---|---|
| Weight | 3.30 kg | 7.28 lbs |
| Nominal WLL | 7000 kg | 15,430 lbs |
| T | 104 mm | 4-1/16" |
| B | 32 mm | 1-1/4" |
| C | 29 mm | 1-5/32" |
| D | 73 mm | 2-27/32" |
| E | 76 mm | 3" |
| G | 98 mm | 3-13/16" |
| I | 53 mm | 2-3/32" |
| K | 135 mm | 5-5/16" |
| L | 54 mm | 2-1/8" |
| M | M36 mm | M36 |
| N | 22 mm | 7/8" |
- 360° adjustable in force direction
- several times higher WLL than the DIN 580 eye bolt
- Easy-Fit-Key for easy assembly and disassembly available, look type VRS-F
