KYOCERA Carbide Drill Spiral 1.25MM 07854
These drill bits come in standard sizes expressed in millimeters and have a drilling diameter of 2mm or less. Carbide micro drill bits provide excellent hardness, wear resistance, and heat resistance. They create precise holes with a smooth finish and often eliminate the need for reaming the hole after drilling.
Carbide bits require a rigid setup such as a fixed-spindle machine. The bright finish on these drill bits is not affected when the bits' cutting edges are resharpened. Spiral-flute drill bits evacuate chips as the bits drill into a workpiece.
Name
KYOCERA Carbide Drill Spiral 1.25MM 07854
Brand
Condition
New
| Material | Carbide |
| Hand of Cut | Right Hand Cut |
| Overall Length | 1.4961 in |
| Number of Flutes | 2 |
| Point Angle | 130 |
| Flute Type | Spiral |
| Shank Configuration | Cylindrical |
| Shank Size | 0.1181 in |
| Length of Cut | 0.4016 in |
| Helix Angle | 33 Degree |
| Drill Diameter | 0.0492 in |
| Flute Length | 0.4016 in |
