KYOCERA Indexable Turning Toolholder SDNCN1212JX11
| Toolholder Style | SDNC |
| Hand of Holder | Neutral |
| Insert Compatibility | DC.. 325.. |
| Insert Holding Method | Screw |
| Overall Length (Decimal Inch) | 4.7244 |
| Shank Width (mm) | 12.00 |
| Shank Height (mm) | 12.00 |
| Rake | Neutral |
| Cutting Direction | Neutral |
| Compatible Insert Size Code | DCMT325; DCGT325; DCET325; DCGW325; DCMW325; DCMX325 |
| Multi-use Tool | Yes |
| Shank Width (Decimal Inch) | 0.4724 |
| Shank Height (Decimal Inch) | 0.4724 |
| Series | SDNC |
| Cutting Tool Application | Copying; Machining |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.2362 |
| Back of Bar to Cutting Edge (mm) | 6.00 |
| Insert Inscribed Circle (Decimal Inch) | 0.3750 |
| Insert Inscribed Circle (Inch) | 3/8 |
| Toolholder Material | Steel |
| UNSPSC Code | 23153308 |
| Insert Thickness | 3.97 |
