KYOCERA TMK00492 Turning Insert CA125P Carbide
Specification
Name
KYOCERA TMK00492 Turning Insert CA125P Carbide
SKU
TMK00492
Brand
Condition
New
| Insert Style | TNMG |
| Insert Size Code | 331 |
| Insert Shape | Triangle |
| Included Angle | 60.00 |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Corner Radius (Decimal Inch) | 0.0158 |
| Corner Radius (mm) | 0.40 |
| Insert Material | Carbide |
| Manufacturer Grade | CA125P |
| Coating/Finish | TiCN/Al2O3/TiN |
| Relief Angle | 0.000 |
| Wiper Edge | No |
| Insert Thickness | 4.76 |
| Insert Thickness (Decimal Inch) | 0.1874 |
| Insert Hand | Neutral |
| Number Of Cutting Edges | 6 |
| Insert Shape Code | T |
| Corner Radius (Inch) | 1/64 |
| Hole Diameter (Mm) ( - 0 Decimals) | 3.8100 |
| Hole Diameter (Decimal Inch) | 0.1500 |
| Inscribed Circle (Inch) | 3/8 |
| Inscribed Circle (mm) | 9.53 |
| Insert Holding Method | Screw; Clamp |
| Insert Thickness (Inch) | 3/16 |
| Clearance Code | N |
| Tolerance Code | M |
| Series | ISO Insert |
| Coating Process | CVD |
| Rake | Negative |
| Primary Workpiece Material | Alloy Steel; Carbon Steel |
| Primary Workpiece Material Code | P |
| Secondary Workpiece Material Code | None |
| Iso Code | TNMG160404PMG |
| Manufacturers Catalog Number | TNMG331PMGCA125P |
| UNSPSC Code | 23242107 |
| Chip Breaker | None |
| Multi-Use Tool | Yes |
| Multi-Use Application | External Turning; Chamfering; Facing; Copying; Boring |
