| Insert Style |
TNMG |
| Insert Size Code |
331 |
| Insert Shape |
Triangle |
| Included Angle |
60 |
| Inscribed Circle (Decimal Inch) |
0.3750 |
| Corner Radius (Decimal Inch) |
0.0156 |
| Corner Radius (mm) |
0.40 |
| Insert Material |
Carbide |
| Manufacturer Grade |
CA6515 |
| Coating/Finish |
TiCN; TiN; Al2O3 |
| Relief Angle |
0 |
| Insert Thickness |
4.76 |
| Insert Thickness (Decimal Inch) |
0.1875 |
| Insert Hand |
Neutral |
| Number Of Cutting Edges |
6 |
| Insert Shape Code |
T |
| Corner Radius (Inch) |
1/64 |
| Hole Diameter (Mm) ( - 0 Decimals) |
3.81 |
| Hole Diameter (Decimal Inch) |
0.1500 |
| Inscribed Circle (Inch) |
3/8 |
| Insert Holding Method |
Pin; Clamp |
| Insert Thickness (Inch) |
3/16 |
| Clearance Code |
N |
| Tolerance Code |
M |
| Series |
ISOI |
| Coating Process |
CVD |
| Rake |
Negative |
| Primary Workpiece Material Code |
M |
| Secondary Workpiece Material |
Superalloy |
| Secondary Workpiece Material Code |
S |
| Iso Code |
TNMG160404MQ |
| Standards |
ISO; ANSI |
| Manufacturers Catalog Number |
TNMG331MQ CA6515 |
| UNSPSC Code |
23242105 |
| Chip Breaker |
MQ |
| Rake Angle |
15 |
| Multi-Use Application |
Turning |
