Sell EX SUS GOLD 8595224 Stub Length HSSE Drill 2.24MM TiN Coating

Add Enquiry Added

EX SUS GOLD 8595224 Stub Length HSSE Drill 2.24MM TiN Coating

The Ex-SUS-Gold drill line is famous worldwide for its incredible performace gummy materials, like stainless steel. Its high helix and refine X-thinning point geometry yield incredible sharpness, which make it the ideal solution for processing soft materials.

Features
Specification
X-Thining Point Geometry : No center drills neeeded. Achieves high accuracy high shearing forces ideal in gummy materials.
HSS-Vanadium Substrate : Added heat resistance via 3% Vanadium content yields superior performance to standard High Speed Steel drills.
Titanium Nitride Coating : Increased hardness and lubricitiy inceases wear resistance thereby extending tool fe.
Name
EX SUS GOLD 8595224 Stub Length HSSE Drill 2.24MM TiN Coating
SKU
8595224
Condition
New

			Shank Diameter
			3MM

			Overall Length
			45MM

			Number of Flutes
			2

			Type
			Stub Length HSSE Drill

			Angle
			130Deg

			Coating Material
			TiN

			Diameter
			2.24MM

			Flute Type
			Spiral

			Point Type
			Four Facet Point

			Material
			Vanadium High Speed Steel

			Sub-brand
			EX-SUS-GOLD

			Hole Depth
			≤ 3xD

			Decimal Equivalent
			0.0882

			Series / List
			1100

			Flute Length
			13MM

Shank Diameter	3MM
Overall Length	45MM
Number of Flutes	2
Type	Stub Length HSSE Drill
Angle	130Deg
Coating Material	TiN
Diameter	2.24MM
Flute Type	Spiral
Point Type	Four Facet Point
Material	Vanadium High Speed Steel
Sub-brand	EX-SUS-GOLD
Hole Depth	≤ 3xD
Decimal Equivalent	0.0882
Series / List	1100
Flute Length	13MM
