Pferd TC -BURRS CONCAVE RADIUS BURRS V EDGE 1612/6 R3 ECS EAN 4007220098028

Concave radius burrs for the production of precise radii. Cannot be re-sharpened. Suitable for the production and processing of 3 mm outer radii.

Product Description
Specification

Concave radius burrs for the production of precise radii. Cannot be re-sharpened. Suitable for the production and processing of 3 mm outer radii.

Materials that can be worked:

  • Cobalt-based alloys
  • Other non-ferrous metals
  • High-temperature-resistant materials
  • Nickel-based alloys (e. g. Inconell and Hasteloy)
  • Hard non-ferrous metal
  • Titanium
  • Titanium alloys
  • soft non-ferrous metal
  • Copper
  • Soft non-ferrous metal
  • Brass
  • Zinc
  • Cast iron
  • Grey/nodular cast iron (GG/GJL, GGG/GJS)
  • Annealed cast iron
  • Black cast iron (GTS, GJMB)
  • White annealed cast iron (GTW, GJMW)
  • Steel, cast steel
  • Hardened, heat-treated steels over 1,200 N/mm2 (over 38 HRC)
  • Case-hardened steels
  • Tool steels
  • Steel
  • Steels up to 1,200 N/mm² (< 38 HRC)
  • Cast steel

Applications:

  • Deburring
  • Milling
  • Work on edges
  • Chamfering
  • Rounding

Drive types:

  • Flexible shaft drive
  • Straight grinder
  • Stationary machines
  • Robot applications
  • Machine tool
Name
Pferd TC -BURRS CONCAVE RADIUS BURRS V EDGE 1612/6 R3 ECS EAN 4007220098028
SKU
V1612/6EDGER3,0ECS
Brand
Ships from
Batam, Indonesia
Outer dia. 16 mm
Width 3 mm
Shank dia. 6 mm
Overall length 52 mm
Diameterd3 10 mm
Lengthl3 24 mm
Diameter d4 25 mm
Radius r 3 mm
Cut EDGE
