Universal Epoxy Resin Adhesive WEICON Epoxy Minute Adhesive LOCTITE 3422
WEICON Epoxy Minute Adhesive can be used on numerous materials such as metal, plastic, fibre-reinforced materials, ceramics, glass, stone and wood. The adhesive is suitable for construction and assembly works whenever the use of the WEICON Easy-Mix System is inefficient.
LOCTITE® EA 3422 is a pale yellow/white translucent color (when mixed), 2-part, slightly thixotropic epoxy adhesive which cures rapidly at room temperature after mixing. It is a general purpose, non-sag adhesive which develops high strength on a wide range of substrates. Gap filling makes this adhesive suitable for rough or poorly fitting surfaces made from metals, ceramic, rigid plastics or wood.
Specification
Name
Universal Epoxy Resin Adhesive WEICON Epoxy Minute Adhesive LOCTITE 3422
Brand
Condition
New
| WEICON SPESIFICATION | |
| Base | Epoxy resin, non-filled |
| Filler | Unfilled |
| Texture | Viscous |
| Colour | Transparent |
| Processing Temperature | +10°C to +30°C |
| Curing Temperature | +6°C to +40°C |
| Mixing Ratio by Weight | 1:1 |
| Viscosity of the Mixture at +20°C | 8,500 mPa·s |
| Density of the Mixture | 1.15 g/cm³ |
| Gap Bridging | Up to max. 2 mm |
| Pot Life at 20°C, 10 ml Batch | 3-4 min. |
| Handling Strength (35% Strength) | 30 min. |
| Working Strength after (50% Strength) | 1 h |
| Final Strength (100% Strength) | 24 h |
| Shrinkage | 2.0% |
| LOCTITE SPESIFICATION | |
| Fixture time | 7.0 min. |
| Mix ratio, by volume | 1 : 1 |
| Color, Mixed | White |
| Pot life, Mixed @ 25.0 °C 10 g mass | 25.0 min. |
| Color, Resin | White |
| Viscosity, Brookfield - RVT, Resin @ 25.0 °C Spindle 6, speed 5 rpm | 45000.0 - 90000.0 mPa·s (cP) |
| Color, Hardener | Yellow |
| Viscosity, Brookfield - RVT, Hardener @ 25.0 °C Spindle 6, speed 5 rpm | 25000.0 - 50000.0 mPa·s (cP) |
