RUD VRS-3.2t-M27 Vario Eye Bolt Starpoint
- 360° adjustable in force direction
- several times higher WLL than the DIN 580 eye bolt
- Easy-Fit-Key for easy assembly and disassembly available, look type VRS-F
Specification
Name
RUD VRS-3.2t-M27 Vario Eye Bolt Starpoint
SKU
VRS-3.2t-M27
Brand
Condition
New
| Attribute | Value (Metric) | Value (Imperial) |
|---|---|---|
| Weight | 0.94 kg | 2.07 lbs |
| Nominal WLL | 3200 kg | 7050 lbs |
| T | 70 mm | 2-3/4" |
| B | 20 mm | 3/4" |
| C | 19 mm | 3/4" |
| D | 49 mm | 1-15/16" |
| E | 51 mm | 2" |
| G | 60 mm | 2-3/8" |
| I | 35 mm | 1-3/8" |
| K | 92 mm | 3-5/8" |
| L | 36 mm | 1-27/64" |
| M | M27 mm | M27 |
| N | 14 mm | 9/16" |
