RUD VLBG-PLUS-4.5t-M24 Load Ring with ICE-bolt
- Optimum WLL with captive but exchangable ICE-Bolt
- Bracket adjustable in force direction
- Comprehensive range of threads
- DNV certification from size M30.
Specification
Name
RUD VLBG-PLUS-4.5t-M24 Load Ring with ICE-bolt
SKU
VLBG-PLUS-4.5t-M24
Brand
Condition
New
| Attribute | Value (Metric) | Value (Imperial) |
|---|---|---|
| Weight | 1.40 kg | 3.09 lbs |
| Nominal WLL | 4500 kg | 9920 lbs |
| T | 125 mm | 4-15/16" |
| A | 50 mm | 1-31/32" |
| B | 82 mm | 3-1/4" |
| C | 54 mm | 2-1/8" |
| D | 45 mm | 1-25/32" |
| E | 67 mm | 2-5/8" |
| F | 17 mm | 23/32" |
| G | 43 mm | 1-11/16" |
| H | 37 mm | 1-7/16" |
| I | 130 mm | 5-1/8" |
| K | 78 mm | 3-1/16" |
| L | 80 mm | 3-1/8" |
| M | M24 mm | M24 |
| N | 48 mm | 1-7/8" |
