RUD VRS-1.5t-M16 Vario Eye Bolt Starpoint
- 360° adjustable in force direction
- several times higher WLL than the DIN 580 eye bolt
- Easy-Fit-Key for easy assembly and disassembly available, look type VRS-F
Specification
Name
RUD VRS-1.5t-M16 Vario Eye Bolt Starpoint
SKU
VRS-1.5t-M16
Brand
Condition
New
| Attribute | Value (Metric) | Value (Imperial) |
|---|---|---|
| Weight | 0.32 kg | 0.71 lbs |
| Nominal WLL | 1500 kg | 3300 lbs |
| T | 49 mm | 1-15/16" |
| B | 15 mm | 19/32" |
| C | 13 mm | 1/2" |
| D | 35 mm | 1-3/8" |
| E | 36 mm | 1-27/64" |
| G | 40 mm | 1-9/16" |
| I | 23.5 mm | 59/64" |
| K | 65 mm | 2-9/16" |
| L | 24 mm | 15/16" |
| M | M16 mm | M16 |
| N | 10 mm | 3/8" |
