Merkur X48 Airless Sprayer High-Pressure Airless Sprayers for Protective Coatings
Features
Specification
- Portable and lightweight – weighs just 99 pounds (45 kgs) and easy to maneuver
- Compact size lets you spray in the smallest areas
- Ideal for one-gun applications using up to 0.025 in tip
- Powerful – sprays medium to high solids coating materials at pressures up to 4800 psi (330 bar)
- Affordable – get high quality results with minimal investment
- Flexible – ideal for a wide range of applications, including marine, rail and steel fabrication
Name
Merkur X48 Airless Sprayer High-Pressure Airless Sprayers for Protective Coatings
Brand
Condition
New
| Merkur High Pressure Sprayer | |
| Maximum pump air inlet pressure |
0.7 MPa, 7 bar |
| Ambient air temperature range |
2°–49°C |
| Maximum fluid temperature |
71°C |
| Sound data |
See Merkur Air Motor Technical Data |
| Weight |
45 kg |
| Maximum fluid working pressure | |
| 16U920, 16V175 |
33 MPa, 330 bar |
| 16U918, 16V174 |
50 MPa, 500 bar |
| Ratio | |
| 16U920, 16V175 |
48:1 |
| 16U918, 16V174 |
72:1 |
| Wetted Parts | |
| Displacement pump |
Stainless steel, plated carbon steel, tungsten carbide with 6% nickel, UHMWPE, PTF |
| Spray gun |
See manual XTR guns technical data |
| Fluid hoses |
nylon |
| Suction assembly |
carbon steel, aluminum, nylon |
