Pipe and Thread Sealing Slow Cure WEICONLOCK AN 305-11 LOCTITE 511
Specification
Name
Pipe and Thread Sealing Slow Cure WEICONLOCK AN 305-11 LOCTITE 511
SKU
AN 305-11
Brand
Condition
New
| WEICON SPESIFICATION | ||
| Colour | white | |
| Fluorescent | no | |
| For thread connections up to | M 80 R 3" | |
| Viscosity | 17.000 - 50.000 ht mPa·s | |
| Gap bridging up to max. | 0,4 mm | |
| Breakaway torque | 7 - 10 Nm | |
| Prevail torque | 2 - 4 Nm | |
| Shear strength Nmm² (DIN 54452) | 4 - 6 N/mm² | |
| Handling strength | 20 - 40 min | |
| Final strength | (100 % strength) | 5-10 h |
| Temperature resistance | -60 to +150 degree C | |
| Compressive strength (free cutting steel / grub screw = 8.8) | ||
| M_3x6 | max. | 1500 bar |
| M_4x6 | max. | 1500 bar |
| M_5x8 | max. | 1500 bar |
| M_6x10 | max. | 1500 bar |
| M_8x12 | max. | 600 bar |
| M_10x16 | max. | 200 bar |
| LOCTITE SPESIFICATION | |
| Agency approvals / certificates / specifications | DVGW |
| Chemical basis / base | Methacrylate |
| Color | Off White |
| Key characteristics | Disassembly: Easy Disassembly, Thixotropic |
| Viscosity, Brookfield - RVT, @ 25.0 degree C Spindle 6, speed 2.5 rpm | 40000.0 - 100000.0 mPa·s (cP) |
| Viscosity, Brookfield - RVT, @ 25.0 degree C Spindle 6, speed 20 rpm | 9000.0 - 22000.0 mPa·s (cP) |
