PFERD TC Burrs Concave radius burrs V 1612/6 EDGE R3 EAN 4007220952412
Concave radius burrs for the production of precise radii. Cannot be re-sharpened. Suitable for the production and processing of 3 mm outer radii.
Materials that can be worked:
- Cobalt-based alloys
- Other non-ferrous metals
- High-temperature-resistant materials
- Nickel-based alloys (e. g. Inconell and Hasteloy)
- Hard non-ferrous metal
- Titanium
- Titanium alloys
- Copper
- Soft non-ferrous metal
- Brass
- Zinc
- Cast iron
- Grey/nodular cast iron (GG/GJL, GGG/GJS)
- Annealed cast iron
- Black cast iron (GTS, GJMB)
- White annealed cast iron (GTW, GJMW)
- Steel, cast steel
- Hardened, heat-treated steels over 1,200 N/mm2 (over 38 HRC)
- Case-hardened steels
- Tool steels
- Steel
- Steels up to 1,200 N/mm² (< 38 HRC)
- Cast steel
Applications:
- Deburring
- Milling
- Work on edges
- Chamfering
- Rounding
Drive types:
- Flexible shaft drive
- Straight grinder
- Stationary machines
- Robot applications
- Machine tool
Specification
Name
PFERD TC Burrs Concave radius burrs V 1612/6 EDGE R3 EAN 4007220952412
SKU
4007220952412
Brand
Condition
New
| Outer dia. | 16 mm |
| Width | 3 mm |
| Shank dia. | 6 mm |
| Overall length | 52 mm |
| Diameter d3 | 10 mm |
| Length l3 | 12 mm |
| Radius r | 3 mm |
| Cut | EDGE |
