PFERD TC Burr Tree Shape with Radius End KEL Dia. 08 x 20MM EAN Z3P Universal Medium Cross Cut 4007220955581
Cut 3 PLUS is cross cut and especially well-suited to machining of cast iron, steel, stainless steel (INOX), nickel-based alloys and titanium alloys. It is characterized by its high stock removal rate.
Tungsten carbide burrs for general applications are suitable for fine and coarse stock removal on the key materials used in industrial manufacturing. They provide a good stock removal rate and are not specific to a particular material.
Conical burr with round radius end according to DIN 8032 with cut conforming to DIN 8033.
Name
PFERD TC Burr Tree Shape with Radius End KEL Dia. 08 x 20MM EAN Z3P Universal Medium Cross Cut 4007220955581
Brand
Condition
New
| Angle | 16 Degree |
| Cut | 3 PLUS |
| Dia. external | 8 mm |
| Dia. shank | 6 mm |
| Length, cut | 20 mm |
| Length, total | 2,362 |
| Length, total | 60 mm |
| RPM from, grey cast iron, white cast iron | 18000 RPM |
| RPM from, hard non-ferrous metals | 10000 RPM |
| RPM from, hardened, heat-treated steels over 1,200 N/mm² | 10000 RPM |
| RPM from, rust and acid-resistant steels | 10000 RPM |
| RPM from, soft non-ferrous metals | 18000 RPM |
| RPM to, grey cast iron, white cast iron | 24000 RPM |
| RPM to, hard non-ferrous metals | 14000 RPM |
| RPM to, hardened, heat-treated steels over 1,200 N/mm² | 14000 RPM |
| RPM to, rust and acid-resistant steels | 14000 RPM |
| RPM to, soft non-ferrous metals | 24000 RPM |
| Radius corner design | 1.25 mm |
| Materials that can be worked | Applications |
|
|
| Drive types | |
|
