PFERD TC Burr Ball KUD Dia. 04 x 03MM EAN 4007220046791
Cut 3 PLUS is cross cut and especially well-suited to machining of cast iron, steel, stainless steel (INOX), nickel-based alloys and titanium alloys. It is characterized by its high stock removal rate.
Tungsten carbide burrs for general applications are suitable for fine and coarse stock removal on the key materials used in industrial manufacturing. They provide a good stock removal rate and are not specific to a particular material.
Ball-shaped burr according to DIN 8032 with cut conforming to DIN 8033.
Name
PFERD TC Burr Ball KUD Dia. 04 x 03MM EAN 4007220046791
Brand
Condition
New
| Cut | 3 PLUS |
| Dia. external | 4 mm |
| Dia. shank | 6 mm |
| Length, cut | 3 mm |
| Length, total | 1,771 |
| Length, total | 45 mm |
| RPM from, grey cast iron, white cast iron | 36000 RPM |
| RPM from, hardened, heat-treated steels over 1,200 N/mm² | 20000 RPM |
| RPM from, high-temperature-resistant materials | 20000 RPM |
| RPM from, rust and acid-resistant steels | 20000 RPM |
| RPM from, steels up to 1,200 N/mm² | 36000 RPM |
| RPM to, grey cast iron, white cast iron | 48000 RPM |
| RPM to, hardened, heat-treated steels over 1,200 N/mm² | 28000 RPM |
| RPM to, high-temperature-resistant materials | 36000 RPM |
| RPM to, rust and acid-resistant steels | 28000 RPM |
| RPM to, steels up to 1,200 N/mm² | 48000 RPM |
| Materials that can be worked | Applications |
|
|
| Drive types | |
|
