PFERD Mounted Flap Wheel F 8050/6 A150 EAN 4007220155912
On mounted flap wheels, the flaps made of coated abrasive are arranged radially around the tool axis in a fan-type structure. Their flexibility enables them to adapt perfectly to the contours of the workpiece. The abrasive grain is embedded in the sturdy, flexible cloth backing material by means of a resinoid bond.
In ISO 3919, mounted flap wheels are designated as "flap wheels with shaft".
For general applications from coarse to fine grinding.
Name
PFERD Mounted Flap Wheel F 8050/6 A150 EAN 4007220155912
Brand
Condition
New
| Opt. RPM from | 4800 RPM |
| Max. RPM | 9500 RPM |
| Outer dia. | 80 mm |
| Width | 50 mm |
| Grit size | 150 |
For universal applications from coarse to fine grinding.
Materials that can be worked:
- Aluminium
- Copper
- Other non-ferrous metals
- Soft non-ferrous metal
- Brass
- Stainless steel (INOX)
- Grey/nodular cast iron (GG/GJL, GGG/GJS)
- Annealed cast iron
- Hardened, heat-treated steels over 1,200 N/mm2 (over 38 HRC)
- Steel materials with a hardness over 54 HRC
- Steel, cast steel
- Steels up to 1,200 N/mm² (< 38 HRC)
- Cast steel
Applications:
- Leveling
- Deburring
- Surface work
- Weld dressing
- Structuring (matt finishing, brush matting and satin finishing)
- Fine grinding in multiple steps
Drive types:
- Flexible shaft drive
- Straight grinder
