PFERD Diamond Grinding Points DZY-N 12,0-8/6 D 91 EAN 4007220261002
The cylindrical shape ZY is suitable for grinding bores, radii and contours using stationary or handheld equipment. Grinding points with a diameter of 8 mm or more have a recess on the front surface.
A = stepped shank
N = non-stepped shank
| Materials that can be worked : | Applications : |
| 1. Nickel- or titanium-based superalloys 2. Other non-ferrous metals 3. High-temperature-resistant materials 4. Ferrite (magnetic material) 5. Glass 6. Graphite and synthetic carbon 7. Tungsten carbide 8. Abrasive materials 9. Technical ceramics |
1. Grinding out 2. Deburring 3. Internal grinding 4. Work on edges (chamfering, rounding) 5. Work on edges 6. Fine finishing |
| Drive types : | |
| 1. Flexible shaft drive 2. Straight grinder 3. Robot applications 4. Stationary machines 5. Machine tool |
Name
PFERD Diamond Grinding Points DZY-N 12,0-8/6 D 91 EAN 4007220261002
Brand
Condition
New
| Outer dia. | 12 mm |
| Width | 8 mm |
| Shank dia. | 6 mm |
| Shank length | 52 mm |
| Grit size | D 91 |
