NITTO KOHKI Hi-Coupla (30PM)
| Model Number | 30 PM |
|---|---|
| Unit | 1pc |
| Material (Seal) | Nitrile rubber |
| Pressure resistance | 2.0MPa (20kgf/cm2) |
| Dimension Bp | 7.5mm |
| Opponent Mounting Size | Rc3/8(PT3/8) |
| Installation Shape | Male thread |
| Dimension Lp | 42mm |
| Valve Structure | No valve |
| Maximum Working Pressure | 1.5MPa |
| Dimension Bd | 7.5mm |
| Dimension A | 14mm |
| Operating Temperature Range | -20 to +80 Degree C |
| Screw Diameter T | R3/8 |
| Dimensions C | 20mm |
| Dimension Hp | Hex 19mm |
| Socket or Plug | plug |
| Fluid | air |
| Material (Body) | Steel (chrome plating) |
