Lifting Ring VLBS HV16+4 Steel 10.000Kg
- Quick and easy mounting
- 2 internal patented distance lugs enhance the seat of the hook and support the springs
- High dynamic and static strength
- 100% electromagnetically crack-tested
- The welding block is forged out of a good welding material S355J2+N (St 52-3N) in any desired position
- The spring also reduces vibration induced noise
- Can be used up to -20 Degree C (-4 Degree F)
- 180 Degree swivelling suspension bracket
Name
Lifting Ring VLBS HV16+4 Steel 10.000Kg
Condition
New
| Working load limit | 10000,00 kg |
| Max. operating temperature | 400,00 Degree C |
| Min. operating temperature | -40,00 Degree C |
| Explosion protection | No |
| Material | Steel |
| Inner Width | 67,00 mm |
| Inner Height | 71,00 mm |
| Attachment type | Weldable |
| Welding seam | HV16+4 |
| Perm. load capacity 90 Degree | 10000,00 kg |
| Rotates under load | No |
| Material thickness | 27,00 mm |
| Holding spring for susp. link | No |
| Swivel range suspension link | 180,00 Degree |
| Colour | pink |
| Surface treatment | Powder-coated |
| Standard | DIN EN 1677-1 |
| Product description | Lifting Ring |
| Manufacturer | RUD |
| Short text product descr. | Lifting Ring |
| Type designation | VLBS |
