KISWEL high tensile strength steel KI-101LF
Features
Specification
| Sizes (mm) | Standard | Welding Position (View+) | Shielding Gas | Polarity | |
| 2.6~6.0 |
KS D 7004 AWS A5.1 EN ISO 2560-A EN ISO 2560-B JIS Z 3221 |
E4301 E6019 E38 2 RA 12 E6019 |
F, HF, H, VU, OH | - | AC/DC(+) |
| Typical chemical composition all-weld metal (%) | ||||||||
| C | Si | Mn | P | S | Cr | Ni | Mo | Remark |
| 0.7 | 0.15 | 0.47 | 0.020 | 0.012 | 0.02 | 0.01 | 0.01 | - |
| Typical chemical properties all-weld metal | |||||
| Y.S (MPa) | Y.S (MPa) | El. (%) | Hardness (HV) | IV (J) | PHWT |
| 400 | 490 | 30 | - | 80 (-20 Degree C) | - |
Name
KISWEL high tensile strength steel KI-101LF
Brand
Condition
New
| Welding Position | Sizes (mm) | Ampere (A) | Volt (V) | ||
| Min. | Max | Min. | Max | ||
| F, HF | 2.6mm | 60 | 90 | ||
| VU, OH | 2.6mm | 50 | 75 | ||
| F, HF | 3.2mm | 80 | 135 | ||
| VU, OH | 3.2mm | 60 | 120 | ||
| F, HF | 4.0mm | 135 | 190 | ||
| VU, OH | 4.0mm | 100 | 160 | ||
| F, HF | 5.0mm | 180 | 240 | ||
| VU, OH | 5.0mm | 135 | 210 | ||
| F, HF | 6.0mm | 250 | 310 | ||
