Sell HOLEX 4045197008572 HSS Jobber Twist Drill 1.7MM

Add Enquiry Added

HOLEX 4045197008572 HSS Jobber Twist Drill 1.7MM

Rolled execution, normal helix angle, core thickness and taper.
Dimensions in accordance with DIN 338.
No structural interruptions, therefore more flexible and suitable for robust drilling work (e.g. with hand drills). Economical execution.

Specification
Name
HOLEX 4045197008572 HSS Jobber Twist Drill 1.7MM
SKU
4045197008572
Condition
New

			Steel < 500 N/mm² m/min
			suitable

			Steel < 900 N/mm² m/min
			suitable

			Steel < 750 N/mm² m/min
			suitable

			Aluminum (short chipping) m/min
			limited fit

			Oil
			suitable

			wet max.
			suitable

			dry
			limited fit

			Collar color
			without

			Cutting material
			HSS extension

			Coating
			uncoated

			Product type
			Twist drill

			Maximum recommended drilling depth L 2 , mm
			17.5

			Nominal DC , mm
			1.7

			Nominal tolerance
			h8

			tang
			cylindrical shank

			Number of Z cutting edges
			2

			Sharpening angle, Grad
			118

			Chip flute length L c , mm
			20

			Feed f in steel < 750 N/mm 2 , mm/U
			0.03

			Overall length L, mm
			43

			Shank D s , mm
			1.7

Steel < 500 N/mm² m/min	suitable
Steel < 900 N/mm² m/min	suitable
Steel < 750 N/mm² m/min	suitable
Aluminum (short chipping) m/min	limited fit
Oil	suitable
wet max.	suitable
dry	limited fit
Collar color	without
Cutting material	HSS extension
Coating	uncoated
Product type	Twist drill
Maximum recommended drilling depth L 2 , mm	17.5
Nominal DC , mm	1.7
Nominal tolerance	h8
tang	cylindrical shank
Number of Z cutting edges	2
Sharpening angle, Grad	118
Chip flute length L c , mm	20
Feed f in steel < 750 N/mm 2 , mm/U	0.03
Overall length L, mm	43
Shank D s , mm	1.7
