HellermannTyton Cable Tie Mount for Screw Fixation, Wmax=12.7mm, ⌀10.29 mm, ⌀10.3 mm, 3/8

HellermannTyton Cable Tie Mount for Screw Fixation, Wmax=12.7mm, ⌀10.29 mm, ⌀10.3 mm, 3/8" (M10) Screw, Black, 100pcs.

Add Enquiry Added to Enquiry
These heavy duty mounts (HDM) have been primarily designed for use in the automotive and truck industry. Nowadays they can be found in a variety of applications requiring heavy duty mounting in areas like the railway, defence and/or agriculture industry.

- Design offers secure alignment to the bundle

- Possible replacement of cushion clamps and/or metal clamps

- Eliminates the needs for multiple sized fix diameter clamps

- For heavy duty cable ties up to 13.5 mm width

- Easy maintenance of bundle by simply changing the cable tie


Name
HellermannTyton Cable Tie Mount for Screw Fixation, Wmax=12.7mm, ⌀10.29 mm, ⌀10.3 mm, 3/8" (M10) Screw, Black, 100pcs.
Brand
HellermannTyton
Condition
New

Specification

ColourBlack (BK)
Fixation MethodScrew Mounting and Rivet
For TiesT50 - T250
Key product featuresvibration absorbing, for multiple routing
MaterialPolyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
Mounting Screw Type3/8" (M10) Screw
PART DESCRIPTIONHDM375BDM4W-R-PA66HIRHSUV-BK
Package Content100pcs.
Package Content packed inpack
Product FamilyHigh Torque Double Mounts (metal bushing)
Product GroupHarness Clip for Heavy Duty Applications, for Screws or Bolts
Short DescriptionFixing mount 89x35,6 mm black
TypeHDM375BDM4W-R
UV-StabilisedYes
Weight/Unit0.035675kg
Fixing Hole Centres (F)0.405"
Height (H)25.2mm
Length (L)89.0mm
Strap Width max. (G)0.5"
Strap Width max. (G)12.7mm
Stud ⌀0.41"
Stud ⌀10.3 mm
Width (W)34.1mm
for Hole ⌀ (FH)10.29 mm
CE CertificationNo
CSA CertifiedNo
ELV compliant (Article 4 - 2)Yes
FlammabilityUL 94 HB
Hazardous GoodsNo
Max. Torque (Nm)154.6Nm
Max. Torque (lbf-In)114.0lbf-ft
Operating Temperature-40 °C to +105 °C
ROHS compliantYes
