Count on Graco XM PFP for accurate, on-ratio mixing
- Handles two-part epoxy intumescent fire protection coatings from 1:1 to 10:1
- Provides precise ratio control
- If off-ratio conditions occur, the system will automatically stop
- Offers data reporting for verification the material was properly applied
- Monitors, tracks and collects data for: mix ratio, pressure, temperature, flow rates and material usage
- USB port to easily download data reports
- Accurate, on-ratio mixing reduces material waste
- Virtually eliminates the difficult task of removing improperly mixed material
- Offers peace of mind with "set and forget" parameter settings
| XM PFP | |
| U.S. |
Metric |
| Mix Ratio Range |
1:1-10:1 (in 0.01 increments) |
| Ratio Tolerance Range (before alarm) |
+/- 5% |
| Maximum Flow Rate (measured with oil) |
13.6 liters per minute |
| Fluid Viscosity Range |
Handles mastic materials which are loaded into heated tankswith ram-fed priming piston pumps |
| Air Inlet |
1 in. npt(f) |
| Fluid Inlets |
Pail (Feed Pumps) |
| Maximum Fluid Working Pressure for A and B Materials |
41 MPa, 414 bar |
| Maximum Fluid Working Pressure for Flushing |
31 MPa, 310 bar |
| Maximum Fluid Working Pressure for Heating |
0.7 MPa, 7 bar |
| Maximum Fluid Temperature |
70°C |
| System Inlet Supplied Air Pressure Range |
0.5-1.0 MPa, 5.5-10.3 bar |
| Maximum Pump Air Pressure |
0.7 MPa, 7 bar |
| Maximum Tank Air Pressure |
0.6 MPa, 6 bar |
| Air Filtration |
40 micron main filter, 5 micron control air filter |
| Ambient Operating Temperature Range |
0 to 54°C |
| Ambient Storage Temperature Range |
-1 to 71°C |
| Environmental Conditions Rating |
Altitude up to 4000 m |
| Sound Pressure * |
86 dBA at 0.7 MPa, 7 bar |
| Sound Power ** |
98 dBA at 0.7 MPa, 7 bar |
| System Weight (empty, no fluid) |
987 kg |
| Air Consumption | |
| Minimum |
2.8 meter³/min |
| Maximum |
7.1 meter³/min |
| Typical Application |
3.5-5.0 meter³/min |
| Power Requirements | |
| Voltage (can be set with jumpers) |
Option 1: 220-240V, 3 phase DELTA (3 wire plus ground) Option 2: 380-400V, 3 phase WYE (4 wire including neutral plus ground) |
| Wattage |
18,400 watts (23,400 with optional flush water heater) |
| Amps |
240V, 3-phase models: 65 Amps per phase full load: 380V, 3-phase models: 38 Amps per phase full load |
| Wetted Parts | |
| Suction Tube (Flush) |
Aluminum |
| Tanks |
Stainless Steel |
| Flush Pump |
Carbide, PTFE, stainless steel, UHMWPE |
| Hoses |
Nylon |
| A and B Metering and Feed Pumps |
Carbon steel, alloy steel, stainless steel, zinc and nickel plating, ductile iron, tungsten carbide, PTFE |
| Dosing Valves |
Carbon Steel, nickel plating, carbide, polyethylene, leather |
| Manifold |
Carbon steel, nickel plating, carbide, stainless steel, PTFE |
| Mixer |
Stainless steel housing with stainless elements |
| Approvals | |
| Machine |
CE, ETL |
| Pressure Tanks |
ASME, CE |
| Notes | |
| * Sound pressure measured 3.3 feet (1 meter) from equipment. | |
| ** Sound power measured per ISO-9614-2. | |
