GRACO ToughTek F340e Portable Fireproofing Pump
Engineered with piston pump technology, ToughTek Fireproofing Pumps deliver high pressures to move fireproofing materials through long hose lengths. Graco's piston pump technology easily handles low, medium and high-density sprayed fire resistive materials (SFRMs), delivering them with a smooth, steady flow rate.
The ToughTek 340e plugs into a standard wall outlet and is compact, portable and easy to move around the job site. This isn't your typical patch pump -- it's much more. Grab the power of ToughTek and get your fireproofing projects done faster and more efficiently.
Grab the power of ToughTek and get done sooner
- Piston pump technology easily handles fireproofing materials
- Gets projects done faster with high-pressure performance
- Electric operation – plugs into a standard 120V, 15A wall outlet
- Long lasting wear parts for more uptime, less downtime
- Easy to use, simple to maintain
- Ideal for fireproofing over structural steel or spray foam insulation
- Features ProGuard System
- Built-in protection system continually monitors operation
- Dual LED indicators provide instant feedback while applying material
- Automatically shuts pump off to protect from thermal overload or excessive pressure
| ToughTek F340e Sprayer | |
| Maximum Fluid Working Pressure |
4.1 MPa, 41 Bar |
| Stroke Length |
57 mm |
| Maximum pump speed (Do not exceed maximum recommended speed of fluid pump to prevent premature pump wear) |
150 cycles per minute |
| Weight (dry) |
95 kg |
| Wetted Parts |
Stainless steel, plated steel, carbide, urethane, PTFE, UHMWPE, LLDPE, aluminum, solvent-resistant o-rings |
| Inlet/Outlet Sizes | |
| Fluid Inlet Size |
3 in. |
| Fluid Outlet Size |
1.5 in. npt(f) with 1.5 in. cam and groove fitting |
| Hose Requirements | |
| Minimum Pressure |
4.1 MPa, 41 Bar |
| Minimum Hose Diameter |
2.5 cm |
| Minimum Hose Length |
7.6 m |
| Power Requirements | |
| 100–120 VAC Models |
1 phase, 50/60 Hz |
| 200–240 VAC Models |
1 phase, 50/60 Hz |
| Noise Level | |
| Sound Power |
90.4 dBa* |
| Sound Pressure |
80.5 dBa* |
