GRACO Fusion Air Purge Plural-Component Spray Gun
Features
Specification
- Easy air-blast tip cleaning reduces build-up and tip clogging.
- Long-lasting side seals means less downtime for maintenance
- Quick-release fluid housing - lets you easily change the mix chambers without tools
- Hand-tightened front cap – no tools needed to clean and maintain seals and mix chamber
- Ergonomic handle
Name
GRACO Fusion Air Purge Plural-Component Spray Gun
Brand
Condition
New
| Fusion Plural Component Impingement Mix Air Purge Spray Gun | |
| Maximum Fluid Working Pressure |
245 bar, 24.5 MPa |
| Minimum Air Inlet Pressure |
5.6 bar, 0.56 MPa |
| Maximum Air Inlet Pressure |
9 bar, 0.9 MPa |
| Air Flow Range |
See chart in instruction manual. |
| Typical Flow Rate of Round Pattern Guns |
See chart in instruction manual. |
| Typical Flow Rate of Flat Pattern Guns |
See chart in instruction manual. |
| Maximum Fluid Temperature |
94°C |
| Air Inlet Size |
1/4 npt Quick Disconnect Nipple |
| A Component (ISO) Inlet Size |
-5 JIC; 1/2-20 UNF |
| B Component (Resin) Inlet Size |
-6 JIC; 9/16-18 UNF |
| Sound Pressure |
81.1 dB(A), using AR5252 at 100 psi (0.7 MPa, 7 bar) |
| Sound Power, measured per ISO 9416–2 |
91.0 dB(A), using AR5252 at 100 psi (0.7 MPa, 7 bar) |
| Dimensions |
191 x 206 x 84 mm |
| Weight |
1.1 kg |
| Wetted Parts |
Aluminum, stainless steel, carbon steel, carbide, chemically resistant o-rings |
