Epoxy Adhesive for Visually Appealing Adhesive Bonds WEICON Easy-Mix N 5000 LOCTITE 9464
WEICON Easy-Mix N 5000 is a transparent, liquid, self-levelling, high-strength adhesive, which has a pot life of 20 minutes. Easy-Mix N 5000 can be used on many materials, such as metal, plastic, fiber composites, ceramics, glass, stone or wood. It is suited for connections where a transparent bond is required.
LOCTITE® EA 9464 is a 2-part, grey structural bonding epoxy adhesive that is fast curing at room temperature and provides a toughened bond. It is therefore ideal for joining dissimilar substrate materials including metals, motorering thermoplastics and thermoset laminates such as SMC. Its thixotropic properties make it good for gap filling and it provides both high peel and shear strength.
Name
Epoxy Adhesive for Visually Appealing Adhesive Bonds WEICON Easy-Mix N 5000 LOCTITE 9464
SKU
N 5000
Brand
Condition
New
| WEICON SPESIFICATION | |
| Base | Epoxy resin, non-filled |
| Texture | Liquid |
| Colour | Almost colourless, crystal clear |
| Processing | |
| Processing temperature | +10°C to +35°C |
| Curing temperature | +6 °C - +40 °C |
| Mixing ratio by weight | 1:1 |
| Viscosity of the mixture at +20 °C | 5,000 mPa·s |
| Density of the mixture | 1.07 g/cm³ |
| Gap bridging | Up to max. 2 mm |
| Curing | |
| Pot life at 20 °C, 10 ml batch | 20 min. |
| Handling strength (35 % strength) | 60 min. |
| Working strength after (50 % strength) | 3 h |
| Final strength (100 % strength) | 48 h |
| LOCTITE SPESIFICATION | |
| Fixture time | 180.0 min. |
| Mix ratio, by volume | 1 : 1 |
| Mix ratio, by weight | 100 : 100 |
| Mixed | |
| Color, Mixed | Gray |
| Pot life, Mixed @ 22.0 °C 100 g mass | 15.0 - 20.0 min. |
| Resin | |
| Color, Resin | White |
| Hardener | |
| Color, Hardener | Black |
