Brushless POWERSTATE™ motor for up to 2x longer motor life and up to 25% more power
REDLINK PLUS™ intelligence system delivers an advanced digital overload protection for tool and battery and uniquely enhances the tool performance under load
REDLITHIUM™-ION battery pack provides superior pack construction, electronics and fade-free performance to deliver more run time and more work over pack life
Second hardest hitting SDS hammer in its class. Powerful hammer mechanism delivers 2.5 J of impact energy at low 8.9 m/s² vibrations
Compact, ergonomic design for increased end user comfort
All metal gear case - optimum seating of the gears for enhanced service life
4-mode operation: rotary hammer, hammer only, rotation only and selectable work position of the chisel (variolock) for maximum versatility
FIXTEC™ system - keyless chuck changing
Individual battery cell monitoring optimises tool run time and ensures long term pack durability
Fuel gauge displays remaining charge
Compatible with M18 CDEX
Flexible battery system: works with all MILWAUKEE® M18™ batteries
| Battery pack capacity (Ah) | 5.0 |
|---|---|
| Battery type | Li-ion |
| Blow energy (EPTA)(J) | 2.5 |
| Charger supplied | 59 min |
| Max. drilling concrete (mm) | 26 |
| Max. drilling steel (mm) | 13 |
| Max. drilling wood (mm) | 30 |
| Max. drilling wood/ steel/ concrete (mm) | 30/ 13/ 26 |
| Max. percussion rate (bpm) | 0 - 5100 |
| No load speed (rpm) | 0 - 1400 |
| No. of batteries supplied | 2 |
| Optimised drilling capacity in concrete (mm) | ø 6 - 20 |
| Standard equipment | Side handle, depth gauge, grease, FIXTEC™ 13 mm full metal chuck |
| Supplied in | HD Box |
| Vibration chiseling (m/s²) | 9.5 |
| Vibration chiselling uncertainty (m/s²) | 1.5 |
| Vibration drilling (m/s²) | 8.9 |
| Voltage (V) | 18 |
| Weight with battery pack (kg) | 3.5 |
