CROSBY S-265 Pivot Link Weld On 1.2 Ton Load Forged Steel (1290740)
Specification
Name
CROSBY S-265 Pivot Link Weld On 1.2 Ton Load Forged Steel (1290740)
SKU
1290740
Brand
Condition
New
| Working Load Limit( t) | Old Stock No. | New Stock No. | Weight (kg) | Dimensions | Min. Fillet Weld Size (mm) |
|||||||
| Design Factor 5:1 | Design Factor 4:1 | A (mm) | B (mm) | C (mm) | D (mm) | F (mm) | G (mm) | H (mm) | ||||
| 1 | 1.2 | 1290740 | 1290839 | 0.4 | 40 | 36 | 83 | 35 | 13 | 66 | 42 | 3 |
| 2.5 | 3.2 | 1290768 | 1290848 | 0.6 | 45 | 44 | 99 | 42 | 18 | 81 | 48 | 3 |
| 4.2 | 5.3 | 1290786 | 1290857 | 1.2 | 55 | 50 | 123 | 49 | 22 | 99 | 57 | 6 |
| 6.4 | 8 | 1290802 | 1290875 | 2.4 | 70 | 64 | 144 | 64 | 26 | 122 | 67 | 6 |
| 12 | 15 | 1290820 | 1290866 | 5.9 | 97 | 90 | 193 | 86 | 34 | 165 | 94 | 8 |
